Explain about fidelity criterion.

1 month ago

The removal of psychovisually redundant data results in a loss of real or quantitative visual information. Because information of interest may be lost, a repeatable or reproducible means of quantifying the nature and extent of information loss is highly desirable. Two general classes of criteria are used as the basis for such an assessment:

  1. Objective fidelity criteria and
  2. Subjective fidelity

When the level of information loss can be expressed as a function of the original or input image and the compressed and subsequently decompressed output image, it is said to be based on an objective fidelity criterion. A good example is the root-mean-square (rms) error between an input and output image. Let f(x, y) represent an input image and let f(x, y) denote an estimate or approximation of f(x, y) that results from compressing and subsequently decompressing the

input. For any value of x and y, the error e(x, y) between f (x, y) and f^ (x, y) can be defined as

so that the total error between the two images is

where the images are of size M X N. The root-mean-square error, erms, between f(x, y) and f^(x, y) then is the square root of the squared error averaged over the M X N array, or

A closely related objective fidelity criterion is the mean-square signal-to-noise ratio of the compressed-decompressed image. If f^ (x, y) is considered to be the sum of the original image f(x, y) and a noise signal e(x, y), the mean-square signal-to-noise ratio of the output image, denoted SNRrms, is

The rms value of the signal-to-noise ratio, denoted SNRrms, is obtained by taking the square root of Eq. above.

Although objective fidelity criteria offer a simple and convenient mechanism for evaluating information loss, most decompressed images ultimately are viewed by humans. Consequently, measuring image quality by the subjective evaluations of a human observer often is more appropriate. This can be accomplished by showing a "typical" decompressed image to an appropriate cross section of viewers and averaging their evaluations. The evaluations may be made using an absolute rating scale or by means of side-by-side comparisons of f(x, y) and f^(x,
